Product Characteristics
1. Air curtain isolation design prevents internal and external cross contamination, with 100% air flow discharged, negative pressure vertical flow, and no need to install pipelines.
2. The front glass can be moved up and down allows for arbitrary positioning which is easy to operate, and complete closure for sterilization. The positioning height limit alarm prompts.
3. The power output socket in the work area is equipped with waterproof sockets and sewage outlets, providing great convenience for operators
4. HEPA filter is installed at the exhaust area to control emission pollution
5. The working area is made of high-quality 304 stainless steel, which is smooth, seamless, and has no dead corners. It can be easily and thoroughly disinfected to prevent corrosion and disinfectant erosion.
6. Controlled by an LCD panel with built-in UV light protection device, it can only be opened when the safety door is closed.
7. Equipped with DOP test port and built-in differential pressure gauge.
8. 10 ° inclination angle, in line with human body design concepts.
Technical Parameters
Model Spec.
YSBSC-1000IIB2
YSBSC-1300IIB2
YSBSC-1600IIB2
Cleanliness
HEPA: ISO 5 (Class100)
Number of colonies
≤0.5pcs/dish·hour (Φ90mm culture plate)
Wind speed
Average suction wind speed: ≥0.55±0.025m/s Average descending wind speed: ≥0.3±0.025m/s
Filtration Efficiency
HEPA of borosilicate glass fiber material: ≥99.995%, @0.3μm
Noise
≤65dB(A)
Vibration half peak
≤5μm
Power
AC single phase 220V/50Hz
Maximum power consumption
1400W
1600W
1800W
Weight
210KG
250KG
270KG
Internal size (mm) W1×D1×H1
1040×650×620
1340×650×620
1640×650×620
External size (mm) W×D×H
1200×800×2270
1500×800×2270
1800×800×2270
HEPA filter specifications and quantity
980×490×50×① 520×380×70×①
1280×490×50×① 820×380×70×①
1580×490×50×① 1120×380×70×①
LED/UV lamp specifications and quantity
12W×②/20W×①
20W×②/30W×①
20W×②/40W×①
